Provides minute-by-minute written record of processing temperature which may be filed for permanent records.
Electronic with digital display, 170/270°F/ 76-132°C, 12 hr. chart drive; 15′ 3-wire sensor cable; 3″ x1/4″ stainless steel bulb, 3/4″ NPT fitting; NEMA rated case with moisture, dust and fume proof hinged door. 100 charts and 2 marking pens.
Recording Retort Thermometer Request Price Specify F° or C° display, 115/60 or 220/50 VAC.
Extra Charts, per 100 Request Price Extra Pens, per 5 pack Request Price Shipping Wt. 20 lbs.
Range 10 to 50 lbs. Steam
VR-1 PressureRegulator, 1/2″ NPT
Request Price
Shipping Wt. 10 lbs.
For Dixie No. 3 Retort pressure cooling applications of glass containers, aluminum and large tin containers.
Request Price
Shipping Wt. 10 lbs.
Install pipe line strainers preceding pressure regulators to keep particles from interfering with operation.
VM-3 1/2″ NPT Request Price
VM-4 3/4″ NPT Request Price
Shipping Wt. 5 lbs. each.
Water is distributed by a fine mist when valve “A” is opened. After cooling to 190° F, valve “B” is opened to admit water through three additional spray nozzles, rapidly cooling to 90° F before reducing to zero pressure and opening the retort.
RD-PW Cooling Water Inlet Assembly
Request Price
White face; black pointer, numbers, and graduations. Drawn steel case with friction steel ring. .Brass socket with square shank for wrench tightening. All have 1/4″ lower connection.
M-54 0 to 30 lbs., 2 1/2″ face Request Price
M-55 0 to 60 lbs., 3 1/2″ face Request Price
M-56 0 to 160 lbs., 3 1/2″ face Request Price
Shipping Wt. 1 lb. each.
Used to prevent reverse flow
NPT Sizes:
1/4″ Request Price
1/2″ Request Price
3/4″ Request Price
1″ Request Price
Shipping Wt. 2 lbs. each.
