Dixie Double Seam Inspection Instruments

Measures seam thickness, seam height, and countersink.

173-C Can Seam Micrometer – Request Price
Graduations: 0.001 inch
Range:
0 to 0.375″ thickness and width;
0 to 0.200″ countersink

173-C-Metric Can Seam Micrometer – Request Price
Graduations: 0.01 mm
Range:
0 to 9.5 mm thickness and width;
0 to 5 mm countersink

For multi-necked beverage or aerosol cans.
Measures seam thickness and seam height.

173-C-SN Can Seam Micrometer – Request Price
Graduations: 0.001 inch
Range:
0 to 0.375″ thickness and width

173-C-SN-Metric Can Seam Micrometer – Request Price
Graduations:0.01 mm
Range:
0 to 9.5 mm thickness and width

End Cutting Nipper – Request Price
For cutting and tearing steel/tin top from double seam. Made of steel with plastic coated handles.

173-A Can Opener – Request Price
For cutting hole in steel/tin top.
Made of stainless steel with wood handle. A fine rasp file may be used to cut through the top (cover) of the double seam to expose cover hook and body hook for measuring.

173 Can Seam Test Kit, 3 Parts …Request Price
Includes Can Opener, Nippers and your choice of Micrometers. (If not otherwise specified, 173-C Micrometer will be included.)

Purpose:

Dixie’s can seam test kit includes the tools needed in the process of can double seam inspection. The disc-cutter type can opener has an adjustable, heavy duty blade which allows you to cut a disc from the can cover without damaging the double seam. The end cutting nipper has perfectly matched hardened jaws to allow cutting through the seam to expose the cover hook, over-lap, and body hook. The can seam micrometers are graduated in thousandths of an inch (or hundredths of a mm) for measuring seam thickness and height. 173-C and 173-C-Metric micrometers feature a depth gauge for measuring countersink.
